Quality Control

Factory Inspection Reports for Custom Metal Promo Orders

Photos Are Not an Inspection Report

Production photos can confirm that a batch exists, but they do not prove that the shipment meets the purchase order. A supplier may send ten attractive close-ups, collect the balance, and the buyer later opens cartons with mixed plating tones, weak clutches, incorrect backstamps, missing barcodes, or hundreds of enamel pins with overflow on the logo. Photos show selected pieces. A usable inspection report shows the sampling plan, measured dimensions, defect counts, tolerances, packing status, and the pass, fail, hold, or rework decision.

For custom enamel pins, challenge coins, keychains, fridge magnets, medals, and badges, the report must connect to the approved artwork, pre-production sample, quotation, and PO. If it does not list size, thickness, base metal, plating, enamel colors, attachment, packing method, carton count, and shipping marks, it is too weak for B2B buying. The report is the final commercial control point before the buyer releases balance payment or authorizes shipment.

The inspection should also reflect product risk. A 25 mm soft enamel pin with a butterfly clutch does not need the same checklist as a 60 mm antique brass challenge coin, a zinc alloy bottle opener keychain, or a nickel-free badge for a child-facing program. The right report is not longer for the sake of paperwork; it is specific enough to expose defects that would trigger returns, distributor chargebacks, or brand complaints.

Define Scope Before Reviewing Defects

The first page should identify exactly what was inspected: PO number, SKU, artwork revision, approved sample date, ordered quantity, finished quantity, inspected quantity, inspection date, carton count, and shipment term such as EXW, FOB Ningbo, FOB Shenzhen, or FOB Shanghai. For repeat orders, the report should reference the locked reorder specification and previous approved sample, not only the latest email thread.

Final random inspection should normally take place when 100 percent of goods are produced and at least 80 percent are packed. Earlier checks can miss carton marking errors, mixed SKUs, missing backing cards, incorrect inner quantities, or attachment shortages. For urgent event orders or technically complex products, add an in-process inspection at 30 to 50 percent completion to catch die, plating, enamel, or assembly problems before the whole batch is finished. That mid-production check reduces risk, but it should not replace final inspection.

Buyers should state whether the inspection includes functional and safety checks. A pin can look correct but fail because the clutch slips off under a 1.5 kg pull. A magnet can pass visually but detach from the metal body. A split ring can open after basic torque. These failures rarely appear in beauty photos, so they must be built into the report.

Report field	Minimum detail to request	Buyer risk controlled
Product reference	PO, SKU, artwork file, revision number, approval date	Prevents inspection against an outdated proof
Lot status	Ordered, finished, packed, and inspected quantities	Shows whether the sampled goods represent the shipment
Sampling plan	ISO 2859-1 or ANSI/ASQ Z1.4 level, sample size, AQL limits	Makes the pass decision statistically meaningful
Critical specifications	Size, thickness, plating, enamel, hardware, packing	Focuses inspection on defects that affect acceptance
Measured results	Actual readings, tolerance, instrument used	Avoids vague checkmarks such as “size OK”
Disposition	Pass, fail, hold, rework, or ship after concession	Creates a clear basis for payment and release

Use AQL Levels That Match the Order Risk

AQL means acceptable quality limit. It does not mean zero defects. It defines how many defects are allowed in a random sample before the lot fails. For most custom metal promotional products, buyers use ISO 2859-1 or ANSI/ASQ Z1.4 General Inspection Level II with AQL 0 for critical defects, AQL 2.5 for major defects, and AQL 4.0 for minor defects. For retail merchandise, licensed artwork, nickel-free claims, or premium gifts, use tighter limits such as AQL 1.5 for major defects and 2.5 for minor defects.

Critical defects create safety, compliance, or serious brand risk. Examples include sharp burrs above 0.2 mm on wearable items, detached magnets that create small-part hazards, wrong client logo, wrong event date, undeclared nickel plating where nickel-free was specified, or an attachment that can injure the user. One critical defect should normally fail the lot.

Major defects affect saleability or function. Examples include wrong plating finish, missing enamel in visible areas, bent pin posts, size outside tolerance, weak split rings, loose brooch needles, missing backing cards, wrong barcode, or carton labels that do not match the SKU. Minor defects are small cosmetic issues that do not affect use, such as polishing marks below 0.5 mm, slight soft enamel waviness, or tiny color specks not visible at 30 cm under normal white light.

Order quantity	Level II sample size	AQL 2.5 major reject at	AQL 4.0 minor reject at
500 pcs	50 pcs	4 defects	6 defects
1,000 pcs	80 pcs	6 defects	8 defects
3,000 pcs	125 pcs	8 defects	11 defects
5,000 pcs	200 pcs	11 defects	15 defects
10,000 pcs	315 pcs	15 defects	22 defects

The reject-at number is the failure point. For example, if 1,000 keychains are inspected at Level II, the sample size is 80 pieces. Under AQL 2.5, five major defects may still pass, but six major defects fail the lot. That distinction matters when deciding whether to release payment, accept a discount, or require sorting and reinspection.

Measure Dimensions Against the Approved Sample

Custom metal items are small, so small deviations are visible. A 2 mm error on a 25 mm lapel pin changes the design balance. A pin post placed 0.8 mm off-center can make a badge rotate on fabric. A 0.3 mm thickness shortfall on a challenge coin can make the item feel cheap even when the artwork is correct. Inspection reports should show actual measurements from digital calipers accurate to 0.01 mm, not only a tick box.

For die-struck iron or brass pins, practical size tolerance is usually ±0.3 mm for simple shapes and ±0.5 mm for irregular outline badges. Zinc alloy casting normally needs ±0.5 to ±0.8 mm because shrinkage, openwork, and polishing loss are harder to control. Challenge coins can often be held to ±0.3 mm on diameter and ±0.2 mm on thickness for simple round designs; 3D relief, cutouts, or irregular edging may require wider tolerances agreed before tooling.

Weight should be recorded for coins, bottle opener keychains, medals, and premium badges. A 40 mm × 3 mm zinc alloy coin may vary by ±5 percent after casting and polishing. A brass coin made from consistent blanks should be tighter, often ±3 percent. If the item is sold as premium merchandise, specify target weight in the PO and require at least 10 randomly selected pieces to be weighed.

• Check outside diameter, longest width, and shortest width with 0.01 mm digital calipers.
• Measure thickness at three points, excluding raised 3D relief unless total height is specified.
• Record pin post position from the top edge and centerline for badges over 30 mm.
• Measure magnet diameter and thickness before assembly when holding force is critical.
• Weigh at least 10 pieces for coins, bottle openers, medals, and heavy brooches.
• Compare results with both the approved drawing and the physical pre-production sample.

Make Surface, Plating, and Enamel Limits Measurable

Visual standards must be written so both buyer and factory can apply them consistently. “No scratches” is not realistic for polished metal products because microscopic handling marks can occur during plating, drying, and packing. A better standard is: no visible scratch longer than 1 mm on the front face when viewed at 30 cm under 600 to 800 lux white light. For retail goods, shorten the limit to 0.5 mm or require individual protective film or bagging.

Plating thickness should be defined by process, not just color. Promotional gold flash on pins and badges may be only 0.03 to 0.08 microns and is suitable for short-term giveaways. A more durable decorative gold layer is commonly 0.1 to 0.3 microns. Base nickel layers are much thicker, often around 3 to 8 microns before the decorative top layer. Antique brass, antique copper, black nickel, and dyed finishes should be checked for shade consistency across cartons, because mixed bath conditions can create visible lot-to-lot differences.

Enamel inspection should separate fill height, contamination, color match, and polishing damage. Soft enamel normally sits 0.1 to 0.3 mm below the metal lines. Hard enamel is polished nearly flush, typically within ±0.05 mm of the metal surface after finishing. Pantone matching should be judged under D65 or cool white lighting against the approved sample, because enamel pigment, plating reflection, epoxy doming, and cure temperature can shift perceived color.

Feature	Recommended inspection limit	Tighten for
Front scratches	No visible scratch over 1 mm at 30 cm viewing distance	Retail, paid merchandise, luxury brand gifts
Enamel overflow	None crossing metal lines on logos, letters, or faces	Small text, mascots, licensed designs
Soft enamel fill	Recessed 0.1 to 0.3 mm below raised metal	No epoxy dome or high-contrast plating
Hard enamel flatness	Flush within ±0.05 mm after polishing	Minimalist logos and mirror finishes
Gold top layer	Specify flash, 0.1 micron, or 0.3 micron	Humid storage or premium programs
Sharp burrs	No burr over 0.2 mm on edges or cutouts	Wearables and child-facing promotions

Test Hardware, Function, and Assembly

Many returns are caused by hardware rather than artwork. Butterfly clutches feel loose when the spring is weak. Rubber clutches fall off when the post diameter is inconsistent. Split rings open when wire hardness is too low. Magnets fail when the glue area is too small or the surface was not cleaned before bonding. These checks should appear as measured or repeated tests, not casual comments.

For lapel pins, common post diameter is 0.9 to 1.2 mm and common length is 8 to 10 mm. The post should be perpendicular enough that the clutch seats fully without wobble. A basic retention test should confirm the clutch does not detach under a 1.5 to 2.0 kg pull unless the buyer specifies a heavier standard. For brooches, the needle and safety clasp should open and close smoothly for at least 10 cycles during inspection without bending or loosening.

For keychains, promotional split ring wire is commonly 1.0 to 1.5 mm. Heavier charms and bottle openers should use 1.6 to 2.0 mm wire. Jump rings should be fully closed, with a visible gap under 0.2 mm. Larger gaps catch fabric, weaken the assembly, and cause charm loss. For magnets, inspectors should test adhesion on a clean steel plate and confirm that the magnet does not separate from the product under normal hand pull.

• Pins: check post straightness, solder strength, clutch fit, anti-rotation placement, and spare clutch count.
• Keychains: check split ring hardness, jump ring closure, swivel movement, plating wear, and charm orientation.
• Coins: check edge text, reeded edge consistency, enamel fill, serial numbers, and capsule fit.
• Magnets: check magnet polarity, glue overflow, holding force, and separator packing to prevent scratches.
• Medals: check ribbon width, clip closure, loop strength, plating at the lug, and individual bagging.
• Bottle openers: check opening edge, plating coverage inside cutouts, and function on a standard cap.

Inspect Packing, Labels, and Mixed SKUs

A product can pass visual inspection and still fail receiving if the packing is wrong. Pins packed loose in one large bag scratch during ocean freight. Coins without separators rub through antique finish. Mixed SKUs with wrong carton labels create warehouse delays, distributor chargebacks, and inventory errors. Packing inspection should verify both protection and traceability.

For individual bags, common PE or OPP thickness is 0.03 to 0.05 mm. Backing cards for pins are usually 250 to 350 gsm coated paper, while retail cards may use 400 gsm stock, lamination, or hang holes. Export cartons are normally 5-ply corrugated board. For dense metal items, keep gross weight below 15 kg per carton where possible; use 18 kg only when the buyer accepts heavier handling and the carton strength is upgraded.

Inspection should confirm inner quantity, master carton quantity, barcode labels, country-of-origin marking if required, shipping marks, gross and net weights, carton dimensions, and moisture protection. For sea freight, humid destinations, antique finishes, plated iron, or paper cards, specify desiccant and sealed inner bags. The report should include photos of one fully packed carton opened in layers, not just one sample item on a desk.

Packing item	Typical specification	Inspection risk
Individual polybag	0.03 to 0.05 mm PE or OPP	Thin bags tear; no bag causes scratches
Backing card	250 to 350 gsm for promo, 400 gsm for retail	Wrong card bends pins or hides artwork
Coin capsule	Clear PS or acrylic matched to coin diameter	Loose fit causes rubbing; tight fit cracks
Inner box	100 to 500 pcs depending on item weight	Overpacking creates pressure marks and bent posts
Export carton	5-ply corrugated, under 15 kg preferred	Weak cartons collapse in stacked transport
Carton label	SKU, PO, quantity, gross weight, carton number	Wrong labels delay receiving and inventory control

Connect Inspection to Cost, Lead Time, and Shipment Release

Inspection has a cost even when performed inside the factory. Measuring, sorting, reworking, relabeling, scanning, and repacking all consume labor. For a simple 1,000-piece soft enamel pin order, standard internal final QC may be included in the FOB price. For a 10,000-piece mixed-SKU order with individual barcodes, backing cards, and carton allocation by warehouse, inspection and packing verification can add 1 to 3 working days.

Third-party inspection in China commonly costs USD 180 to USD 350 per man-day, depending on city, travel, report format, and whether testing requires special fixtures. Factory internal inspection is normally included in standard FOB pricing, but tight requirements such as 100 percent visual sorting, individual weight checks, QR code scanning, nickel-release lab testing, or salt-spray testing must be quoted separately. AQL inspection and 100 percent inspection should never be priced as if they are the same workload.

FOB impact depends on product complexity. A 25 mm soft enamel pin at 1,000 pieces may sit around USD 0.45 to USD 1.20 per piece FOB, depending on base metal, plating, colors, mold amortization, and packing. Adding backing card verification, barcode scanning, and extra cosmetic sorting may add USD 0.03 to USD 0.10 per piece. A 45 mm zinc alloy keychain may range from USD 0.90 to USD 2.40 FOB, while a 50 mm challenge coin can range from USD 1.80 to USD 5.50 depending on thickness, edge, plating, enamel, and capsule packing.

Before placing the next order, attach a one-page QC appendix to the PO. List the approved sample reference, AQL levels, measurement tolerances, defect definitions, hardware tests, packing method, labeling rules, required report photos, and who has authority to approve concessions. This prevents the common dispute where the buyer expects retail-grade sorting but the supplier quoted standard promotional inspection.

For low-risk giveaways under 500 pieces and repeat designs, a concise internal report may be enough. For retail, licensed, child-facing, nickel-free, multi-SKU, or high-value orders, request a full AQL report and consider third-party inspection before balance payment. If a supplier resists measurable inspection terms, treat it as a sourcing risk. Quality control should be priced and scheduled before production starts, not negotiated after the cartons are packed.
